• Brand: XI
• Net weight:250 grams
• Working Range: 550 to 800°C
• General purpose: use as silver brazing flux.
• Good fluidity, high activity and medium life.
• Provide effective fluxing on the common engineering materials , such as copper, copper alloys (brass), mild steel and stainless steel, but not aluminum.
• This product meets specification of AWS Type FB3A, DIN 8511, Federal Specification O-F-499d, (Type B).
• Please use with care and follow the safety instructions.
NOTE: Please use with care and follow the safety instructions.
Safety Precaution:
1. Avoid contact with skin, eyes or clothing.
2. Use safety goggles, rubber gloves and rubber apron.
3.Wash hand thoroughly after using it.
4. Keep away from harmful vapor/ fumes/ gases produced.
5. In case of contact with eyes, flush freely with water and contact physician.
6. If swallowed, drink large amount of water and meet physician immediately.
Directions For Use:
This product is a silver brazing flux. It is intended for use with silver brazing filler metals that melt below 750° C. If use it correctly, it will provide effective fluxing on the common engineering metals, such as copper, copper alloys(brass), mild steel and stainless steel, but not on aluminum. The working temperature range is 550 - 800° C.
1.Clean and degrease the joint surface before applying flux.
2. Mix flux powder with water and a few drops of liquid detergent to form a thick paste.
3. Brush paste onto the joint surfaces before assembly and externally other side of the joint opening.
4. Easy-flo Flux powder adheres well to a warmed brazing rod allowing flux to be transferred to the joint area via the rod. It can be used to supplement a pre-fluxed area during heating.
5. Heat evenly to a brazing temperature. Avoid localized overheating.
6.If blackening of the component or flux occurs, this is a sign of insufficient flux, overheating or flux exhaustion.
7. Remove flux residues by soaking and then brushing in hot water.
